Product Details

Mechanical tire curing press (horizontal type) with single mold is used for mass production of heavy radial truck tires such as for construction machinery and tractors to meet customers' requirements for cost-effective curing presses.


Technical parameters

ModelUnitLLB-75"LLB-88"LLB-95"LLB-105"LLB-122"
Number of steam chamberpcs11111
Nominal diameter of steam chambermmΦ1900Φ2250Φ2410Φ2665Φ3100
Max. mold closing forceKN6480940095101368517200
Mold heightmm380-710550-920650-940600-1200800-1250
Structural style of center mechanism
BOMBOMBOMBOMBOM
Heating method
DOMEDOMEDOMEDOMEDOME
Diameter of applicable beadinch24-3324-3324-3324-4024-35
Max. diameter of green tiremm16301900195521002500
Max. height of green tiremm12001600160018001250
